Specification :

Model Name : A620MS

CPU SUPPORT : Socket AM5 support AMD Ryzen 7000 / 8000 / 9000 series Processors

MEMORY :

AMD Ryzen 7000 / 8000 / 9000 Series Processors:

Supports Dual Channel DDR5 – 6000+(OC) MT/s, Non-ECC, Un-buffered Memory

2 x DDR5 DIMM Memory Slot, Max. Supports up to 128 GB Memory

Support Intel Extreme Memory Profile (XMP) memory modules and AMD EXTended Profiles for Overclocking (EXPO) memory modules

INTEGRATED VIDEO :

By CPU model

Supports DX12

Supports HDCP

STORAGE :

Total support 1 x M.2 Socket and 4 x SATA (6Gb/s) ports

AMD Ryzen 7000 / 8000 / 9000 Series Processors

1x M.2 (Key M) Socket (M2M_CPU) :

Supports M.2 Type 2242/ 2260/ 2280 SSD module

Supports PCIe 4.0 x4 (64Gb/s) – NVMe SSD

AMD A620 Chipset

4x SATA III Connector (6Gb/s) : Supports AHCI & RAID 0, 1, 10

LAN :

Realtek RTL8111H
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

AUDIO CODEC :

ALC897
7.1 Channels, High Definition Audio, Hi-Fi

USB :

6 x USB 3.2 Gen1 port (4 on rear I/Os and 2 via internal headers)

6 x USB 2.0 port (2 on rear I/Os and 4 via internal headers)

EXPANSION SLOT :

AMD Ryzen 7000 / 8000 / 9000 Series Processors

1 x PCIe 4.0 x16 Slot (x16 or x8/x8 mode)

AMD A620 Chipset

1 x PCIe 3.0 x1 Slot

REAR I/O :

1 x SMART BIOS UPDATE Button

1 x HDMI Port (HDMI1.4)

1 x DP Port (DP1.2)

4 x USB 3.2 (Gen1) Type-A Port

2 x USB 2.0 Type-A Port

1 x Giga LAN port

3 x Audio Jack

INTERNAL I/O :

4 x SATA III Connector (6Gb/s)

2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

1 x 8-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x System Fan Connector

1 x CPU water cooling connector (CPU_OPT)

1 x Front Panel Header

1 x Front Audio Header

1 x Speaker Header

1 x Clear CMOS Header

1 x COM Port Header

1 x TPM Header

H/W MONITORING :

CPU / System Temperature Monitoring

CPU / System Fan Monitoring

Smart / Manual CPU Fan Control

CPU/DDR Voltage Monitoring

DIMENSION : Micro ATX Form Factor Dimension: 22.1cm x 23.5cm ( W x L )
