Specification :

Model No. : PH-ES524XM_DMW01

Case Dimensions : 454 x 228 x 588 mm | 17.87 x 8.98 x 23.15 in

From Factor : Mid-Tower

Mainboard Support : E-ATX | ATX | Micro-ATX | Mini-ITX

*Up to 280 mm wide

Rear ATX Mainboard Support : MSI Project Zero | ASUS BTF | Gigabyte Project Stealth

Materials : Steel chassis | Aluminium panels | Tempered glass window | ABS plastic | Polyester

Expansion Slots : 8

Vertical GPU Support : Yes

Internal 2.5″ Positions :

5 + 1x 3.5″ HDD

Internal 3.5″ Positions

2 + 3x 2.5″ SSD

Front I/O :

2x USB 3.0

1x USB-C 3.2 Gen2x2

1x Microphone | Headphone combo

Power button

Reset button

Matrix Display :

LED Amount : 900

Power Input : 5V | 5.3A

Fabric Material : Polyester

Connectors :

Mainboard USB 2.0 header 500 mm

SATA 500 mm

Fans 120 | 140

– Total Fans : 7 | –

– Top : 3 | –

– Front : – | –

– Side : – | –

– Rear : 1 | –

– Bottom : 3 | –

Radiator 120 | 140
– Top : Max. 360 | –
– Front : – | –
– Rear : – | –
– Bottom : – | –

Clearance

CPU Cooler :

Height : 170 mm | 6.69 in

GPU

Length : 380 mm | 14.96 in

GPU

Width : 170 mm | 6.69 in

Power Supply : 250 mm | 9.84 in

Top 360 Radiator

Length x Width x Height : 415 x 130 x 32 mm | 16.34 x 5.12 x 1.25 in
