Silakan konfirmasi stock sebelum melakukan pembelian 🙂

Specification :

Chipset : AMD A520

CPU Supports : AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors

Socket AM4

Memory : 2x DDR4, Maximum Memory Capacity 64GB

Onboard Graphics :

1x HDMI

Support HDMITM 1.4, maximum resolution of 4K 30Hz

Slot :

1x PCI-E x16 slot

1x PCI-E x1 slot

PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset)

PCI_E2 Gen PCIe 3.0 supports up to x16 (From CPU)

Audio :

Realtek ALC897 Codec

7.1-Channel High Definition Audio

Storage :

1x M.2

M.2_1 Source (From CPU) supports up to PCIe 3.0 x4 / SATA mode, supports 2280/2260 devices

4x SATA 6G

RAID : Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices

USB :

2x USB 2.0 (Rear)

4x USB 2.0 (Front)

4x USB 5Gbps Type A (Rear)

2x USB 5Gbps Type A (Front)

LAN : Realtek RTL8111H 1Gbps LAN

Internal I/O :

1x Power Connector(ATX_PWR)

1x Power Connector(CPU_PWR)

1x CPU Fan

1x System Fan

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Front Audio (JAUD)

1x Com Port (JCOM)

4x USB 2.0 ports

2x USB 5Gbps Type A ports

PCB Info :

mATX

200mmx236mm
